Industrial Spring Hanger is a dedicated support device for industrial piping systems. It is designed to bear the dead weight of pipelines, compensate for displacement caused by thermal expansion and contraction, and isolate mechanical vibration. Since 2012, Yangzhou Tianshun Piping has focused on the R&D and manufacturing of such products. Over the past 14 years, we have produced more than 500,000 sets, which are widely adopted in high-standard industrial projects across the globe. Our products are manufactured in strict accordance with international standards, delivering both standard and customized solutions to suit diverse working conditions.
Leveraging the elastic properties of springs, Industrial Spring Hanger maintains a constant supporting force when pipelines produce vertical displacement. When pipelines expand or contract due to temperature changes, the springs stretch and compress accordingly. This ensures pipeline loads are evenly transmitted to building structures, preventing pipe rupture and equipment damage resulting from stress concentration caused by rigid constraints. Meanwhile, the damping effect of springs effectively absorbs vibration generated by pumps, compressors and other equipment, and reduces noise transmission.
| Variable Spring Hanger Spec Table | Example |
| Hanger Type / Configuration | Type A, B, C, D, E, F, G |
| Spring Size / No. | No. 0 - No. 22 |
| Travel Range | 30mm, 60mm, 90mm, 120mm 180 mm |
| Operating Load | 0.2 kN - 400 kN |
| Installed Load (Cold Load) | kN / kgf |
| Operating Load (Hot Load) | kN / kgf |
| Movement Direction | Upward / Downward |
| Variability (%) | ≤ 25% (Standard) |
| Surface Treatment | Hot Dip Galv/ Painted |
| Housing Material | Carbon Steel (Q235/Q355) |
▶ High load accuracy: Every unit is load-calibrated before delivery, with the load error controlled within ±5%.
▶ Excellent fatigue resistance: All springs have passed 100,000-cycle fatigue tests without permanent deformation or fracture.
▶ High safety factor: The design safety factor is no less than 1.5, ensuring reliable performance under extreme working conditions.
▶ Superior anti-corrosion performance: Finished with hot-dip galvanizing or epoxy zinc-rich coating, suitable for corrosive environments such as coastal areas and chemical plants.
▶ Visual monitoring: Fitted with clear displacement scales for easy on-site installation and operational inspection.
Comparison Items | Ordinary Products on the Market | Tianshun Industrial Spring Hanger |
Spring Material | Ordinary carbon steel | 60Si2MnA / 50CrVA spring steel |
Heat Treatment Process | Single quenching | Three-stage heat treatment (Quenching + Tempering + Stabilization treatment) |
Load Tolerance | ±10% ~ ±15% | Within ±5% |
Fatigue Life | 30,000 cycles | Over 100,000 cycles |
Surface Treatment | Ordinary paint coating | Hot-dip galvanizing / Epoxy zinc-rich primer + topcoat |
Inspection Standard | Sampling inspection | 100% full inspection |
Industrial Spring Hanger is applicable to all industrial piping systems subject to temperature fluctuation and vibration. It performs exceptionally well in the following scenarios:
▶ High-temperature and high-pressure process pipelines for petroleum refining units
▶ Main steam pipelines and feedwater pipelines of power plants
▶ Cryogenic pipelines at LNG receiving terminals and gasification plants
▶ Pipelines conveying corrosive media in chemical and pharmaceutical factories
▶ Main trunk pipelines of urban central heating networks
▶ Gas and oxygen pipelines in iron and steel metallurgical plants
We have established a complete full-process quality control system covering raw material incoming inspection to finished product delivery.
1.Incoming raw material inspection: Each batch of steel is supplied with original material certificates, and tested via spectral analysis and mechanical property examination.
2.Spring production control: Springs are produced by CNC coiling machines. Every spring undergoes load testing and permanent compression deformation test.
3.Welding quality control: All welding procedures are carried out by certified welders, followed by non-destructive testing.
4.Finished product delivery inspection: Each unit is subject to load calibration and visual inspection, with complete quality certification documents provided.
Our production management system has passed ISO 9001:2015 certification, and all products comply with international standards including CE and API.
▶ Free technical selection service: We provide professional hanger selection and calculation based on pipeline parameters and actual working conditions.
▶ Customized design: Non-standard design for special load, displacement or limited installation space requirements.
▶ On-site technical support: Professional engineers can be dispatched to guide on-site installation and commissioning.
▶ Long-term spare parts supply: We maintain a well-equipped spare parts warehouse to deliver prompt support for spare parts demands.
For more technical parameters or customized solutions of Industrial Spring Hanger, please contact our sales team to obtain detailed documents.
