Pipeline systems in petrochemical plants operate long-term under high temperature, high pressure, highly corrosive and flammable/explosive environments, and require 3-5 years of continuous non-stop operation. Under such conditions, ordinary industrial spring supports are prone to spring fatigue fracture, housing corrosion perforation and loose connections. These issues not only cause pipeline stress concentration leading to media leakage, but also may result in unplanned plant shutdowns, bringing economic losses of tens of millions of yuan.
Targeting these industry-specific risks, we have developed the dedicated Petrochemical Variable Spring Support, which is fully adapted to the stringent requirements of the petrochemical industry from materials and structure to manufacturing processes.
The Petrochemical Variable Spring Support is an elastic pipeline support product designed exclusively for petrochemical plants. It absorbs vertical displacement caused by pipeline thermal expansion and contraction through the elastic deformation of springs, while uniformly transmitting pipeline loads to civil structures.
Yangzhou Tianshun Pipeline entered the petrochemical pipeline support field in 2012. Over the past 14 years, we have supplied more than 1.2 million sets of products to over 280 refining, ethylene and LNG projects worldwide, with product performance verified by actual working conditions for up to 12 years.
| Variable Spring Hanger Spec Table | Example |
| Hanger Type / Configuration | Type A, B, C, D, E, F, G |
| Spring Size / No. | No. 0 - No. 22 |
| Travel Range | 30mm, 60mm, 90mm, 120mm 180 mm |
| Operating Load | 0.2 kN - 400 kN |
| Installed Load (Cold Load) | kN / kgf |
| Operating Load (Hot Load) | kN / kgf |
| Movement Direction | Upward / Downward |
| Variability (%) | ≤ 25% (Standard) |
| Surface Treatment | Hot Dip Galv/ Painted |
| Housing Material | Carbon Steel (Q235/Q355) |
Based on the corrosion grade and temperature requirements of different working conditions, we have established a graded material system for Petrochemical Variable Spring Supports to avoid over-engineering or insufficient performance:
▶ Basic Grade: Q345B housing + 60Si2MnA spring, suitable for normal temperature utility pipelines without strong corrosion
▶ Advanced Grade: 304 stainless steel housing + 50CrVA spring with hot-dip galvanizing treatment, suitable for medium corrosion and process pipelines below 300℃
▶ Special Grade: 316L / Hastelloy housing + nickel-based high-temperature alloy spring, suitable for strong corrosion, 550℃ high temperature or -196℃ low temperature conditions
All products adopt standardized CNC production processes, with 100% traceability for core procedures:
▶ Spring Coiling: Using German imported CNC spring machines, spring pitch and diameter errors are controlled within 0.1mm
▶ Heat Treatment: Adopting vacuum quenching + three tempering processes to completely eliminate spring internal stress, improving fatigue resistance by 60%
▶ Welding: Using argon arc welding, with 100% penetrant testing on welds to ensure no porosity, cracks or other defects
▶ Surface Treatment: Three processes of sandblasting derusting + epoxy zinc-rich primer + fluorocarbon topcoat, with total coating thickness ≥120μm
|
Comparison Dimension |
General-Purpose Variable Spring Support |
Petrochemical Variable Spring Support |
|
Anti-Corrosion Life |
Ordinary paint, 1-2 years |
Three-layer anti-corrosion, ≥10 years |
|
Explosion-Proof Performance |
No explosion-proof design |
Compliant with ATEX explosion-proof standards, no spark risk |
|
Inspection Coverage |
Sampling inspection, 5% sampling rate |
100% full inspection, each unit comes with test report |
|
Fatigue Life |
50,000-80,000 cycles |
≥150,000 cycles, meeting long-term operation requirements |
|
Material Selection |
Single carbon steel material |
Three-level material system, precisely adapted to working conditions |
Petrochemical Variable Spring Supports are widely used in key installations throughout the petrochemical industry chain:
▶ Crude oil and product oil transmission pipelines in atmospheric and vacuum distillation units
▶ Reaction oil and gas, catalyst circulation pipelines in fluid catalytic cracking units
▶ High-temperature cracking gas and low-temperature ethylene pipelines in ethylene cracking units
▶ High-pressure hydrogen and oil product pipelines in hydrofining units
▶ Liquefied natural gas and BOG gas pipelines in LNG terminals
▶ Inlet/outlet and fire-fighting pipelines in product oil tank farms
We have established a closed-loop quality system from design to after-sales service to ensure that every Petrochemical Variable Spring Support meets the highest safety standards of the petrochemical industry:
▶ Design Control: Using CAE software for stress analysis and structural optimization, all design schemes undergo three-level review
▶ Raw Material Control: All steel is sourced from leading steel mills such as Baosteel and Angang, with each batch subjected to spectral analysis and mechanical property testing
▶ Production Control: Quality control points are set for key processes, with full-time quality inspectors monitoring and recording throughout
▶ Pre-Shipment Control: Each unit undergoes full-stroke load testing and displacement calibration, with material reports, test reports and certificates of conformity issued
▶ After-Sales Control: 12-month warranty period with free repair or replacement of defective products, and lifetime technical support
Our quality management system is certified to ISO 9001:2015, and all products comply with international standards including CE, API and ATEX.
▶ Free Working Condition Assessment and Selection Calculation: Providing professional stress analysis and support/hanger selection solutions based on pipeline parameters and working conditions
▶ Non-Standard Product Customization: One-to-one design services for special load, displacement or installation space requirements
▶ On-Site Installation Guidance: Dispatching certified engineers to guide on-site installation and commissioning
▶ Regular Inspection Service: Providing quarterly inspection and maintenance services for annual cooperation customers
▶ Emergency Spare Parts Response: Establishing a dedicated spare parts warehouse to ensure emergency spare parts are dispatched within 24 hours
Q: Can your Petrochemical Variable Spring Supports be customized with special materials?
A: Yes. In addition to the standard three-level material system, we can provide customizations with special alloys such as Hastelloy C276, Monel 400 and Inconel 625 to adapt to extreme conditions such as strong corrosion and ultra-high temperature. The delivery time for special material products is usually 45-60 days, please consult our sales team for details.
Q: Can this product meet the 3-5 years continuous non-stop operation requirement of petrochemical plants?
A: Yes. Our Petrochemical Variable Spring Supports have passed 150,000 fatigue cycles, and have continuously operated for up to 12 years without failure in actual working conditions. All products adopt dual anti-loosening structure and fully sealed design, effectively preventing loosening and corrosion during operation, fully meeting long-term operation requirements.
Q: What inspection documents are included with each product upon shipment?
A: Each product comes with complete quality certification documents, including: Raw Material Test Certificate (MTC EN 10204 3.1), Spring Load Test Report, Dimensional Inspection Report and Product Certificate of Conformity. If third-party inspection by SGS, BV, TUV or other institutions is required, we can arrange it in advance and issue the corresponding reports.
